TAIYE-D50-DTH Separated Photovoltaic Surface Hydraulic Down-the-hole Drill Rig

TAIYE-D50 multifunctional surface DTH drilling rig is suitable for photovoltaic, mining, transportation and other infrastructure construction, and is your effective assistant in perforation projects.


TAIYE-D50 Tractor Mounted Rig has three characteristics:


High speed: drilling 40,000 holes in three months, hole diameter 250mm, hole depth 1.6m, working 10 hours a day.

Innovation: Sliding drill arm, fine-tuning to align the borehole

Multipurpose: rock and soil are all available


  • 1. Positioning mechanism of multifunctional surface DTH drilling rig

    1. Positioning mechanism of multifunctional surface DTH drilling rig

    TAIYE-D50 drill rig uses side positioning method, equipped with telescopic system, can quickly and accurately locate the drilling position, avoiding waste caused by repeated movement of the rig during positioning .The telescopic system is a telescopic drill arm body and a positioning slide. All sides of the telescopic drill arm body are positioned by polymer plates and can be replaced to ensure the stability of the telescopic boom arm while avoiding the wear and tear of the telescopic boom body during the telescopic process. The stroke is 350mm. The drill arm can swing left and right by 15 °, which guarantees the verticality of drilling on uneven working surfaces.


  • 2. Rotary reducer of multifunctional surface DTH drilling rig

    2. Rotary reducer of multifunctional surface DTH drilling rig

    The two-speed slewing assembly and imported hydraulic motor can adjust the slewing speed and slewing torque of the two-speed slewing assembly according to different rock formations and apertures, so as to achieve the ideal drilling effect. The parallel torque of the motor can reach 4500Nm and the instantaneous torque can reach 5200Nm.


  • 3. Two-speed walking system of multifunctional surface DTH drilling rig

    3. Two-speed walking system of multifunctional surface DTH drilling rig

    The chassis can be optionally equipped with rubber track pads, and a two-speed walking motor is used to achieve the whole machine's walking. Fast walking is used to achieve the fast movement of the whole machine. Low speed walking is mainly used to adjust the position of the opening , so as to accurately align the hole.


  • 4. Dust removal system of multifunctional surface DTH drilling rig

    4. Dust removal system of multifunctional surface DTH drilling rig

    Wet atomizing dust collector, with a capacity of 140L, can guarantee to reduce dust in field construction, effectively improve the air quality of the working environment and reduce the health damage to the construction personnel. This machine can also be equipped with dry dust removal.


Parameter of TAIYE-D50-DTH Separated Photovoltaic Surface Hydraulic Down-the-Hole Drill Rig


Dimension  (mm)5950×2200×3100mm
Weight(Kg)5000kg
Working pressure(Mpa)1.05-2.46Mpa
Drilling hole diameter(DTH)(mm)90-305
Drilling hole diameter(Ratory)(mm)130-300
Grade ability(°)15°
Sliding carriage stroke(mm)2500mm
Double Speed MotorseriesTurning speed(rpm)0-160
Turning torque(N.m)2250
parallelTurning speed(rpm)0-80
Turning torque(N.m)4500
Lifting force(Kg.f)2000
Sliding frame pitching(°)0-105
Drill boom swing(°)left/right15°
dust removal
Two dust removal schemes(Dry or Wet)for users to selection
Engine powerKw56
